Wireless 4LED HD Chip Car Rear View Reverse Parking CAMERA for Crown  2012 Toyota With Connect Bracket

Note:

There has two type of the rear view camera, one is wire type and one is   wireless type，

you can choose by yourself when you make the order.

Features:

· Weatherproof, Can be Used both in car and home.

· support night vision.

· CCD imaging sensor.

· Support NTSC OR PAL Video system.

· High-definition and wide viewing angle.

· Applicable to variety of Vehicles: car, truck, RV, mini-van etc.

· Easy to install, you can install the monitor via mount holder or universal bracket.

· 5m Video cable.

· Can help avoid incidents and accidents abrasion well.

Specification:

· Image Sensor: 1/3 "OV Color

· Effective Pixels: PAL 512 (H)x582 (V); NTSC  512 (H)x492 (V)

· Horizontal Resolution: 420 TVL

· Minimum Illumination: 1.0Lux F=1.2 (0Lux with IR on)

· Night Vision: 5-10meters

· Lens: 2.8mm

· Diagonal Viewing Angle: 120 degree optional

· Synchronization: Internal synchronization

· Signal to noise ratio: >48db

· Signal System: PAL/NTSC

· Electronic Shutter: Auto

· Video Output: RCA interface, 1.0Vp-p, 75Ohm

· White Balance: Auto

· Backlight Compensation: Auto

· Power: DC 12V

· Current Consumption: 50-60mA, Max 130mA with IR on

· Operating Temperature: -20°C~ +60°C, RH95% Max

· Storage Temperature: -30°C ~ +80°C, RH95% Max

· Video cable length: 5m

· Power supply cable length: 150cm

Package Content:

wire camera:

1 x Car Rear View Camera
1 x6M video cable
1 x power supply cable
1 x user manual

Wireless camera :

1X car camera

1set: transitter and receiver

1x user manual

​Advantages:

1.Easy Install Car View Camera:

No Need to drill hole, instead of car license plate Number light cover, Play and plug as a car license plate frame camera

2.High definition with AV plug:

Universal AV Plug connect car monitor Display Screen or car DVD GPS player directly , also could match wireless Video Transmitter Receiver to be a Wireless Car Rear View Camera

3.Night vision and Wide Angle Reverse parking Camera：

With Compensating Light Vehicle Camera ,include Super white LED lights and distance line ,help you see more clearly at night

4.Shock-proof and Waterproof Back Up Parking Camera:

Driver See clearly when Driving or bad weather

5.Universal car rear view camera with 1 year warranty to every customer.

How to Install

Take out your stock license plate light at the back of your car.
Fix the camera to where the stock license plate light was.
Connect the built-in license plate light of the camera to where the stock license plate light was connected to get the power
Connect the power of the camera to your reverse lights - red wire to positive and black wire to negative.
Connect the video cable of the camera to the extension cord.
Connect the extension cord to your car monitor.
You will see the images when your car is in reverse shift.
